V Dia. x 0.377″ Shank × 1-1/4″ Flute Length × 2-1/2″ OAL, 3XD, 118°, Uncoated, 2 Flute, External Coolant, Round Solid Carbide Drill
Alternate Manufacture # 26577
| Drill Bit Size / Cutting Diameter (DC) | V | Shank Type | Round |
| Drill Bit Size / Cutting Diameter (DC) - Letter / Wire Gauge | V | Cutting Edge Material | Carbide |
| Length Group | 3xD | Tool Type | Solid Carbide Drill |
| Coating | Uncoated | Measurement Type | Letter |
| Connection Diameter Machine Side (DCONMS) | 0.377″ | Usable Length (LU) | 1-1/4″ |
| Coolant Supply Property (CSP) | External | Length Chip Flute (LCF) | 1-1/4″ |
| Point Angle (SIG) | 118 Degrees | Overall Length (OAL) | 2-1/2″ |
| Flute Helix Angle (FHA) | 21 Degrees | Flute Count (NOF) | 2 |
Product Features
Family Description
Alternate Manufacture # 26577
Remarks
•Solid Carbide Stub Length Drill
•3X Drill Length
•118 degree point angle
•21 degree helix
•designed to allow high feed rates with good chip flow.
•Four facet drill point minimizes drill wander and assures accurately sized holes.
•Shorter length reduces deflection and vibration, increases drill accuracy and improved tool life.
Country of Origin
UNITED STATES
Shipping Info
Package Length
2.50000
Package Width
.39400
Package Height
.39400
Package Weight
.110
