10 mm Dia. × 10 mm Shank × 19 mm DOC × 72 mm OAL, Carbide TiAlN, 3 Flute, CW|35° Helix, Weldon, Ballnose End Mill
| Cutting Diameter (DC) | 10 mm | Corner Radius (RE) | 5 mm |
| Connection Diameter Machine Side (DCONMS) | 10 mm | End Shape | Ball Nose |
| Depth of Cut Maximum (APMX) | 19 mm | Coolant Supply Property (CSP) | External |
| Overall Length (OAL) | 72 mm | Decimal Equivalent | 0.3937″ |
| Cutting Edge Material | Carbide | Measurement Type | Metric |
| Coating | TiAlN | Series/List # | DC19 |
| Flute Count (NOF) | 3 | Shank Length (LS) | 38 mm |
| Flute Helix Angle (FHA) | 35 Degrees | Cutting Direction (HAND) | Right Hand |
| Shank Type | Weldon | Center Cutting | Yes |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Single / Double End | Single End |
| Application | | Finishing | |
Product Features
Country of Origin
DE
Shipping Info
Package Weight
.1543
